Support

Downloads

SparkShape brochure

Welcome to the future of light – in almost every imaginable form.

Download

Casambi quick reference

Setting up and operating a SparkShape via the Casambi mobile app is quite simple. We'll tell you the fastest way to do it.

Download

Datasheets

Each data sheet is generated individually for your luminaire and takes into account all individually planned parameters of your SparkShape such as shape, size, luminous flux, light distribution, output and many more. You can access the data sheet for your SparkShape via LightSketch.

LightSketch

Mounting instructions

Please use the mounting instructions for installation.

Download

Ceiling mount

Power supply

The power supply can be mounted discreetly so that the weightless design of the luminaire is preserved. For suspended ceilings, we can invisibly power your SparkShape. All that is needed is the specially developed ceiling fixture, as well as a luminaire power supply unit, which, together with the current-carrying suspensions, enables the luminaire to be supplied unnoticed.

Alternatively, we offer two canopy shapes and sizes for mounting on a raw ceiling. If the power outlet on your ceiling is already defined, you can freely position the corresponding location on the SparkShape according to your circumstances.

Canopy angular M

Two-piece canopy for ceiling mounting

  • Rectangular design for 65 W power supply unit
  • external dimensions 180 x 82 x 35 mm³
  • Powder coating matt traffic white RAL 9016
  • Two current-carrying suspension points, matched to mounting of power supply unit
Technical drawing

Canopy angular L

Two-piece canopy for ceiling mounting

  • Rectangular design for 150 W power supply unit
  • external dimensions 235 x 82 x 40 mm³
  • Powder coating matt traffic white RAL 9016
  • Two current-carrying suspension points, matched to mounting of power supply unit
Technical drawing
